Description
Product Features
- Open cabinet with outboard motor & table-mounted trunnion
- Lightest weight, most affordable cast-iron SawStop Saw
- Uses identical Professional T-Glide Fence for 30″ & 52″ rip capacities
- Left tilt blade
included:
- 2 Cast Iron Extension Wings
- Mitre Gauge
- Dust Collection Blade Guard
- Riving Knife
- 2 Blade Wrenches
- Push Stick
- 10″ Blade
- Standard Brake Cartridge
- Owner’s Manual
- 2 Hardware Packs
- 3mm Hex Key
- 5mm Hex Key
- 8mm Hex Key
- Blade Spacing Adjustment Gauge
Product Specifications
| Brand | SawStop |
| Motor | 1.3kW (1.75HP) Induction, 10A plug |
| Switch Type | Special Type |
| Blade Diameter | 10″ |
| Arbor Diameter | 5/8″ |
| Maximum Cut At 45° | 57mm |
| Maximum Cut At 90° | 76mm |
| Blade Guard | Clear, Tilting – Rise & Fall |
| Blade Tilt | Left |
| Dado Capable | 19mm Maximum |
| Drive Type | Ribbed V Belt (AntiStatic) |
| Dust Port | 4″ |
| Maximum Rip Capacity | 927mm |
| Mitre Gauge Included | Yes |
| Riving Knife Style | Quick Release |
| Speed | 4200 RPM |
| Stand Included Or Integral | Open Stand |
| Table Size | 1600mm x 686mm |
| Workshop Footprint (WxDxH) | 1760mm x 1015mm |
| Anti Kickback Pawls? | Yes |
| Fence Style | T Glide Steel |
| Warranty Period | 1 Year |
| Shipping Weight | 150kg |
| Nett Weight | 135Kg |
