Laguna C Flux Cyclone


The c|flux series sets a new standard for cyclones. The horizontal chute is designed to maximize airflow while improving CFM. All shapes and dimensions has been reevaluated to optimize performance.

Available on backorder


Laguna C Flux Cyclone

Product Features

  • The c|flux:3 comes standard with a 1 micron canister providing filtration of 99.7% of particles 1 micron or larger & features 109 sq/ft. of polyester spun bond pleated filter to ensure maximum airflow. 270° manual clean comes standard.
  • The c|flux series can be equipped with an optional auto clean kit either at time of purchase or as an add-on later.
  • The auto clean kit includes a smart sensor that detects a drop in air pressure indicating the filter is getting clogged and automatically activates the cleaning procedure.
  • Ingenious lift system quickly moves the drum off the floor and seals against the drum lid, avoiding the need for a flex hose.
  • This design allows for much better portability as you are not forcing 4 wheels into the floor while pushing the unit.

Technical Information

  • Motor HP: 3 HP
  • Phase: 1 and 3
  • Voltage: 240V & 415V
  • Hertz: 50
  • Plug: No
  • RPM: 2850
  • Switch Type: Radio Frequency Remote switch – Black Box
  • Hand Held Remote Control: High Frequency
  • Real CFM: 1350
  • Nominal CFM: 2340
  • Max Static Pressure (inches of water): 11.2″
  • Impeller/Fan Size: 15.5″
  • Impeller Material: Steel
  • Impeller type: Radial Fin
  • Balanced To: ISO 1940
  • Inlet Diameters: 8″ by 4″ x 3 Ports
  • Drum Capacity: 46 Gal
  • Octagon drum: Metal Drum Insert
  • Drum collection bag (Dia. x L): Plastic bag (610 x 950mmL)
  • Canister Filter type: 1 Micron
  • Filtration efficiency: 0.2-2micron @ 99.97%
  • MERV rating: 12
  • Canister diameter: 400mm (15.75″)
  • Canister length: 900mm (19.69″)
  • Filter Surface Area: 9.5m²
  • Canister cleaning: Manual Handle Crank – *Optional Auto Cleaning Kit available
  • Canister filter lower dust collection: Plastic bag (400 x 600mmL)
  • Base with perforated sheet across canister floor: N/A
  • Wheels: (4x) 4″ Flat Caster
  • Decibel Reading: 88 d B(A) (@9.8ft)
  • Machine weight: 140kgs
  • Shipping weight: 170kgs
  • Assembled Dimensions (L x W x H): 1178x690x2025mm

Additional information

Weight 190 kg
Dimensions 127 × 85 × 190 cm
